Code editor

x/editor provides editor.Editor, a text editor for source code. It adds to a multi-line text field what a code editor needs: coloured syntax, a gutter beside the text, folding, a find bar, and hooks for completion, hover documentation and error markers. Each piece is optional and pluggable, so you can have line numbers without highlighting, or highlighting without a gutter.

Install

go get github.com/belluikit/bellui/x/editor@latest

A first editor

// A Go editor with line numbers and a save handler.
package main

import (
	"log"
	"os"

	"github.com/belluikit/bellui"
	"github.com/belluikit/bellui/app"
	"github.com/belluikit/bellui/geo"

	"github.com/belluikit/bellui/x/editor"
	"github.com/belluikit/bellui/x/editor/highlight/golang"
)

const source = `package main

import "fmt"

// main prints a greeting.
func main() {
	name := "Bellui"
	fmt.Printf("Hello, %s!\n", name)
}
`

func main() {
	a := app.New()
	w := a.NewWindow("main.go")
	w.Resize(geo.NewSize(700, 450))

	ed := editor.NewEditor()
	ed.Highlighter = golang.New()
	ed.Gutter = editor.NewLineNumberGutter()
	ed.SetText(source)

	ed.OnSave = func() { // Cmd+S on macOS
		if err := os.WriteFile("main.go.txt", []byte(ed.Text()), 0o644); err != nil {
			log.Println(err)
		}
	}

	w.SetContent(ed)
	bellui.ShowAndRun(w)
}

• editor.NewEditor creates the widget with sensible defaults: automatic indentation, four-space indents, and at least 20 visible rows.
• Highlighter colours the text; here, the Go highlighter.
• Gutter draws to the left of the text. It stays in place when the text scrolls sideways.
• SetText replaces the whole document. It clears the undo history and does not call OnChanged, which reports only the user’s edits. To change the text the way a user edit would, with undo, use ApplyEdit or ApplyEdits.
• OnSave and OnRun are called for Cmd+S and Cmd+R on macOS. On other systems these, and the find shortcuts below, use the Super (Windows) key in place of Cmd.

Keyboard shortcuts only reach the editor while it has focus: the user clicks into it, or you call Focus() once the window is showing.

SetReadOnly(true) stops editing but keeps the syntax colours. MinRows sets the minimum height in rows, and AutoGrow makes the editor grow with its content, between MinAutoGrowRows and MaxAutoGrowRows.

Syntax highlighting

Four highlighters ship with the module, each in its own package under highlight/:

For another language, implement Highlighter, or wrap a function in HighlighterFunc. The editor calls it once per line. It returns styled runs that together cover the line, and a state number that is passed to the next line, so a construct like a block comment can continue across lines. State 0 means “nothing open”.

var iniHighlighter = editor.HighlighterFunc(func(line string, state int) ([]editor.StyleRun, int) {
	// Colour an INI file: [sections], key = value, and ; comments.
	// No construct spans lines, so the returned state is always 0.
	trimmed := strings.TrimSpace(line)
	switch {
	case strings.HasPrefix(trimmed, ";"):
		return []editor.StyleRun{{Text: line, ColorName: editor.ColorNameSyntaxComment, Italic: true}}, 0
	case strings.HasPrefix(trimmed, "["):
		return []editor.StyleRun{{Text: line, ColorName: editor.ColorNameSyntaxKeyword, Bold: true}}, 0
	}
	key, value, ok := strings.Cut(line, "=")
	if !ok {
		return []editor.StyleRun{{Text: line}}, 0
	}
	// The runs must cover the whole line, in order.
	return []editor.StyleRun{
		{Text: key, ColorName: editor.ColorNameSyntaxType},
		{Text: "=", ColorName: editor.ColorNameSyntaxOperator},
		{Text: value, ColorName: editor.ColorNameSyntaxString},
	}, 0
})

A run names a colour with ColorName rather than a fixed colour, so it follows the theme. The ColorNameSyntax... constants (keyword, string, comment, number, builtin, function, operator, type, annotation) are looked up in your app’s theme first. A theme that does not define them gets built-in light and dark defaults. A run can also set ForegroundColor directly, a BackgroundColor, and bold, italic or underlined text.

The gutter

A GutterProvider draws one column of the gutter. Combine several with NewCompositeGutter:

ed := editor.NewEditor()
ed.Highlighter = starlark.New()
ed.SetText(script)

breakpoints := editor.NewBreakpointGutter(func(lines map[int]bool) {
	status.SetText(fmt.Sprintf("%d breakpoints", len(lines)))
})
// NewCompositeGutter puts the columns in the usual order:
// markers, then line numbers, then fold controls.
ed.Gutter = editor.NewCompositeGutter(
	editor.NewLineNumberGutter(),
	ed.FoldGutter(),
	ed.DiagnosticGutter(),
	breakpoints,
)

Whatever order you pass them in, the composite arranges the columns conventionally: markers (breakpoints, diagnostics) on the outside, line numbers next, and fold controls beside the text. Use NewCompositeGutterInOrder to keep your own order.

The fold and diagnostic gutters belong to the editor, so you get them from it rather than creating new ones. If you change the gutter after the editor is shown, call ApplyGutter.

Folding

The editor does not work out fold regions by itself. You tell it which line ranges can fold, typically from your own parser or language server:

// Rows and columns count from 0.
ed.SetFoldRegions([]editor.FoldRegion{
	{Range: editor.TextRange{StartRow: 0, EndRow: 1}, Kind: editor.FoldKindComment},
	{Range: editor.TextRange{StartRow: 3, EndRow: 9}, Kind: editor.FoldKindBlock},
})

A region with Collapsed: true starts folded; Summary replaces the default ... placeholder. From code, Fold, Unfold, FoldAll and UnfoldAll change the state, and AutoFold folds a range that was not registered.

Diagnostics

A Diagnostic marks a range of text with a severity and a message. The editor draws a wavy underline under the range, a marker in the diagnostic gutter, and shows the message when the pointer rests on the range.

ed.SetDiagnostics([]editor.Diagnostic{
	{
		Range:    editor.TextRange{StartRow: 7, StartCol: 7, EndRow: 7, EndCol: 20},
		Severity: editor.SeverityWarning,
		Message:  "compare with None using 'is'",
		Source:   "lint",
	},
})
ed.SetDiagnosticClickToReveal(true) // clicking a marker moves to the problem

Severities are SeverityError, SeverityWarning, SeverityInfo and SeverityHint. SetDiagnostics replaces the whole set each time, so you can call it whenever your checker finishes; pass nil to clear them. Call it on the UI thread.

Find

Cmd+F opens a find bar above the text (the Super key on Linux and Windows). Typing highlights every match; Enter or Cmd+G moves to the next and Shift+Cmd+G to the previous; Escape closes it. A switch makes the search case sensitive. ShowFind, FindNext, FindPrev and HideFind do the same from code, for example from your own menu.

Completion, hover and signatures

The editor asks providers you install for language help. Each is an interface with one method, called on the UI thread, so it should answer quickly.

ed.SetCompletionProvider(&editor.WordListCompletionProvider{
	Words: []string{"def", "return", "greet", "print", "len"},
	Kind:  editor.CompletionKeyword,
})
ed.SetHoverProvider(&editor.WordHoverProvider{
	Docs: map[string]string{
		"greet": "**greet(name)**\n\nReturns a greeting for `name`.",
	},
	Text: ed.Text,
})

• Completion shows a list of candidates while the user types, or on Ctrl+Space. A CompletionProvider returns CompletionItems with a label, the text to insert, an optional detail and documentation. WordListCompletionProvider offers a fixed list.
• Hover shows a card when the pointer rests on a word, or on Cmd+K Cmd+I (Ctrl+K Ctrl+I on Linux and Windows). A HoverProvider returns markdown or plain text. WordHoverProvider looks words up in a map.
• Signature help shows a function’s parameters when the user types ( or , in a call, or presses Cmd+Shift+Space (Ctrl+Shift+Space on Linux and Windows). Install a SignatureHelpProvider; FuncSignatureProvider reads signatures from a map.
• Go to definition: a LinkProvider marks words that can be followed. Cmd-click on macOS, or Ctrl-click elsewhere, or F12, calls the function you register with OnRequestNavigation.

The interfaces are shaped like the Language Server Protocol’s requests, so a bridge to a language server can implement them, but they carry no LSP types. ed.KeyMap changes the completion, signature and go-to-definition shortcuts; start from editor.DefaultKeyMap().

Decorations

Decorations draw over the text without changing it.

A row decorator draws across a whole line, for example the current line in a debugger. A span decorator draws over a character range: an underline (solid, wavy or dotted), a background, a box or a strike-through.

current := editor.NewCurrentLineDecorator(1) // 1-based
ed.Decorators = []editor.RowDecorator{current}
ed.OnCursorChanged = func(row, col int) { // 0-based
	current.Row = row + 1
	ed.RefreshDecorators()
}

ed.SpanDecorators = []editor.SpanDecorator{&editor.StaticSpanDecorator{
	SpansList: []editor.DecoratedSpan{{
		Range: editor.TextRange{StartRow: 3, StartCol: 0, EndRow: 3, EndCol: 5},
		Kind:  editor.SpanBox,
		Color: color.NRGBA{R: 33, G: 150, B: 243, A: 255},
	}},
}}

Note that CurrentLineDecorator.Row counts lines from 1, while cursor positions and TextRange count from 0. After changing a decorator’s fields, call RefreshDecorators. After replacing the Decorators or SpanDecorators slice, call ApplyDecorators.

Two related features protect parts of the text:

• SetRedactions hides ranges behind an opaque bar, for secrets such as API keys. The caret cannot enter a hidden range, and edits to it are refused.
• SetProtectedRanges makes ranges read-only while the rest stays editable. The ranges move with the text as the user edits above them.

Large documents

The gutter and the decorations are drawn only for the visible lines, so long files stay responsive. For documents of several megabytes, set DeferTextSync: the editor then reports the text to OnChanged at natural pauses (a new line, a deletion, moving to another line, losing focus) instead of on every keystroke.

Licence

x/editor is BSD 3-Clause licensed, like Bellui.
